weight

About 1.5 KG

Dimension

195mm x 287mm x 83.4mm

The range of power

100V - 240V

The maximum power

15W

Work temperature

0 ^oC～40 ^oC

Storage temperature

-10 ^oC～60 ^oC

Relative humidity

< 90%

Number of coordinate

Three axis

Operation key

The sealed siliconce touch-type keyboard

Linear scale port

Model DB-9 home-based port

Linear scale signal

>10mA

Linear scale resolution

It can be set(the resolution including 0.1um, 0.2um, 0.5um,1um, 2um and 5um Etc.)

RS232

Model DB-9 home-based port

（Printer Port）

Centronix interface

Footswitch interface

short circuit contact model

Mini-priter

 (optional)
